50Amp to 200Amp gasoline inverter dc arc welder for industrial construction
inverter dc arc welder
Advantages:
Powered by Kohler/Briggs & Stratton gasoline engine
High frequency arc ignition
Pre and lagging gas supply to ensure good welding quality
Light weight, low failure rate
100% duty cycle for 24-hour continuous operation
Technical Specification:
| Inverter DC Arc Welder | ||
| Type | AXQ1-200T | |
| Welder | No-load Voltage (V) | 60-85 |
| Rated-load Voltage (V) | 22–28 | |
| Welding Output Current (A) | 40–200 | |
| Welding Rod Diameter (Φmm) | 1.2-5 | |
| Welding Method | Hand Welder, MIG Welder | |
| Duty cycle (%) | 100 | |
| Auxiliary power supply | DC220v/3kw | |
| TIG welder arc striking gap (mm) | ≥5 | |
| Argon arc welding current (A) | 10-200 | |
| Pre gas supply(S) | 3 | |
| Post gas supply (S) | 3~8 adjustable | |
| Frequency | High frequency | |
| Engine | Engine Model | KOHLERCH440, B&S2552 (optional) |
| Valve Type | OHV | |
| Displacement | 389 | |
| Ignition system | CDI | |
| Fuel Tank Capacity (L) | 25 | |
| Fuel Consumption (g/HP.hr) | 228 | |
| Oil alarm system | YES | |
| whole set | starting system | Recoil |
| Insulation Class | H | |
| Protection Class | IP21 | |
| Dimensions (mm) | 680×530×605 | |
| Net weight(kg) | 68 | |
Application Scope:
This gasoline dc arc welder is widely used to weld railway tracks, guard rails, natual gas pipes, oil pipelines, and all kinds of black metals.
